Aimpoint Acro P-1 3.5 MOA (Plate Sold Seperately)

Aimpoint Acro C-2

The Aimpoint® Acro C-2 is the next generation in the Acro series with an optimized technology. With the new battery size of CR2032 and new diode technology the Acro C-2 will last for 5 years of continuous use on setting 6/10 (daylight setting) . The new LED gives you a brighter 3.5 MOA dot.

The Acro series includes a wide variety of available mounting solutions, which make it possible to mount the Acro C-2 optic on several weapon platforms such as shotguns and rifles or utilized as a backup sight on magnified scopes. Tested with a minimum of 20,000 rounds on a .40 cal pistol slide, this small optic has proven to lead in ruggedness and reliability.  It is trusted by law enforcement, military, hunters, and sport shooters alike. They all rely on the Acro advantage. The enclosed system makes it reliable and operational in any weather conditions. The Acro C-2 is a lightweight, low-profile optic that provides fast target acquisition and an unlimited field of view.

Features:

• Fully enclosed system
• Variety of mounting options sold separately
• New CR2032 battery that will last for 5 years of continuous use
• Designed for direct integration in combination with mount plates onto optic ready pistol slides
• Fully enclosed housing protects all electronic components of the sight from all elements
• Easily zeroed with the Aimpoint tool that comes with the sight. Adjustment clicks you can hear and feel
• Can be mounted on any Aimpoint Micro sight mount via the Acro mount plate with Micro interface
• Can be used as a secondary sight on magnifying rifle scopes with the Acro adapter rings
• Battery installation while optic is still mounted on weapon
• Anodized high strength aluminum housing, semi-matte black
• NVD compatible

Mounting Specifications:

• Mounting Solution: Integrated Acro™ Interface
• Mounting Platform: Acro™ Interface
• Torque - Mount to Sight: 3.0 Nm / 27 in-lbs
• Torque - Mount to Rail: 3.0 Nm / 27 in-lbs

Environmental Specifications:

• Submersible to: 5 m/ 15 ft
• Laser: No Laser Emission
• Radioactive Material: None
• Temperature Range Operation: - 30°C to + 60°C / - 20°F to + 140°F
• Temperature Range Storage: - 51°C to + 71°C / - 60°F to + 160°F
• Temperature Shock: Operable after a temperature shock between - 30°C and + 60°C / - 22°F and + 140°F
• Humidity - Operable during and after Humidity. Limits: Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
• Shock - Operable before and after shock. Limits: Tested with 20,000 rounds mounted on a .40 S&W caliber pistol slide
• Vibration - Withstands vibration. Limits: Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
• Chemical Resistance: Withstands occasional contamination by weapons cleaners, lubricants, fuels and insect repellents.

Physical Specifications:

• Size L x W x H: 47 x 33 x 31 mm
• Size L x W x H: 1.9 x 1.3 x 1.2 in
• Weight: 60 g (without mounting solution)
• Weight: 2.1 oz (without mounting solution)
• Size L x W x H - Sight Only: 47 x 33 x 31 mm
• Size L x W x H - Sight Only: 1.9 x 1.3 x 1.2 in
• Weight - Sight Only: 60 g
• Weight - Sight Only: 2.1 oz
• Material Housing and Tube: High Strength Aluminum
• Surface Finish Housing: Anodized, Semi-Matte
• Colour Housing: Black
• Lens Covers: Not Included
• Height of Optical Axis: 14 mm / 0.6 in measured from top surface of mounting platform
• Adjustment: 1 Click = 20 mm at 100 m / 0.7 in at 100 yds

Power Source Specifications:

• Battery Life: 50,000 h at daylight setting 6 (15,000 Lux, room temperature)
• Battery Type: CR2032, 3V, Lithium
• Battery Quantity: 1
• Battery Size: CR2032
• Power Switch: Push Buttons
• Night Vision Device (NVD) Settings: 2
• Daylight (DL) Settings: 8
• Start Setting Position: 7

Optical Specifications:

• Dot Size: 3.5 MOA
• Magnification: 1X - No Magnification
• Night Vision Device (NVD) Compatible: Yes
• Transmission: Average 60% in the range 420 - 700 nm
• Eye Relief: Unlimited
• Diode: LED (Light Emitting Diode) totally eye safe
• Dot Colour: Red
• Light Source Wavelength: 650 nm red light
• Optical Coating: Anti-reflex coating all surfaces and multilayer coating objective lens
• Clear Aperature: 15 × 15 mm / 0.59 × 0.59 in
• Parallax: Absence of parallax - No centering required
